Fiber Optic Cables
Multi-Purpose Distribution Cable (MPC-02 ~ MPC-12)
Indoor multi-fiber distribution cable with 900μm tight buffer fibers and aramid yarn strength members, for structured cabling from 2 to 12 fibers.
Key Features
Core construction, certification and fiber count range of our distribution cable line.
Tight Buffer Fiber Construction
Individually color-coded 900μm tight buffer fibers bundled around a central core for indoor distribution wiring.
Aramid Yarn Reinforcement
Aramid yarn strength members provide tensile and crush protection for the fiber bundle.
PVC Outer Jacket
Jacket construction suited for indoor riser and general building distribution routing.
G.652 / G.655 Fiber Compatible
Available with G.652 or G.655 single-mode fiber to match network design requirements.
UL Listed for OFNR
Complies with YD/T 1258.4-2005, ICEA-596, GR-409 and IEC794, and meets UL approval requirements for OFNR.
2 to 12 Fiber Counts
Six standard configurations (MPC-02 to MPC-12) to match distribution and riser cabling needs.
OEM & ODM Capabilities
Custom fiber count, fiber type, jacket color and packaging tailored to your project.
Custom Fiber Count
Fiber count produced to your specified cabling plan, beyond the standard MPC-02 to MPC-12 range.
Fiber Type Selection
G.652 or G.655 single-mode fiber selectable to match your network's dispersion and transmission requirements.
Custom Jacket Color
Outer jacket color produced to your specification for project identification or fiber-type coding.
Custom Length & Packaging
Reel length and spool packaging tailored to your installation and logistics requirements.
Custom Branding & Marking
Customer logo and cable surface marking printed to your brand specification.
Sampling & Volume Production
Small-batch sampling for qualification followed by scalable volume production once specifications are confirmed.
Technical Specifications
General specifications, fiber count snapshot and mechanical dimensions by cable code.
| Standard | YD/T 1258.4-2005, ICEA-596, GR-409, IEC794 |
|---|---|
| Certification | UL Listed (OFNR) |
| Buffer Fiber | 900±50μm tight buffer |
| Strength Member | Aramid yarn |
| Jacket | PVC |
| Fiber Type | G.652 / G.655 |
| Bending Radius | 20× cable diameter (dynamic) / 10× cable diameter (static) |
| Operating Temperature | -20℃ to +60℃ |
| Cable Code | Fiber Count | Cable Diameter |
|---|---|---|
| MPC-02 | 2 | 4.1±0.25mm |
| MPC-06 | 6 | 5.1±0.25mm |
| MPC-12 | 12 | 6.2±0.25mm |
| Custom | On Request | On Request |
| Parameter | MPC-02 | MPC-04 | MPC-06 | MPC-08 | MPC-10 | MPC-12 |
|---|---|---|---|---|---|---|
| Cable Diameter (mm) | 4.1±0.25 | 4.8±0.25 | 5.1±0.25 | 5.6±0.25 | 5.8±0.25 | 6.2±0.25 |
| Cable Weight (kg/km) | On request | 22 | 24 | 27 | On request | 31 |
| TBF Diameter (μm) | 900±50 | 900±50 | 900±50 | 900±50 | 900±50 | 900±50 |
Construction & Configuration
Layer-by-layer breakdown of the buffered fiber core, strength member and outer jacket.
Buffered Fiber Core — 900μm Tight Buffer
Each fiber is individually color-coded and protected by a 900μm tight buffer coating.
Fiber Count Range — 2 to 12 Fibers
Buffered fibers are bundled together in counts from 2 to 12 to match the distribution plan.
Strength Member — Aramid Yarn
Aramid yarn is stranded around the fiber bundle to provide tensile strength and crush resistance.
Outer Jacket — PVC
A PVC outer jacket completes the cable, suited for indoor riser and general building routing.
Bending Performance
Rated for a dynamic bend radius of 20× and a static bend radius of 10× the cable diameter.
Surface Marking
Cable code, fiber count and standard marking are printed on the jacket surface for traceability.
Standards & Test Documentation
Certification, fiber compatibility and environmental temperature ratings.
UL Listed for OFNR
Complies with YD/T 1258.4-2005, ICEA-596, GR-409 and IEC794, and meets UL approval requirements for OFNR riser applications.
G.652 / G.655 Single-Mode
Available with G.652 or G.655 single-mode fiber; full optical attenuation and bandwidth data available in datasheet on request.
-20℃ to +60℃
Operating temperature -20℃ to +60℃; storage -20℃ to +60℃; installation -5℃ to +60℃.
Request a Quote for Distribution Cable
Send us your required fiber count, fiber type (G.652/G.655), jacket color, length and quantity. Our team will review the specification and prepare a quotation for your project.
